Original price was: ₹8,700.00.₹4,590.00Current price is: ₹4,590.00.
Features
Specifications
| Unique Feature |
ASRock Super Alloy
– High Density Glass Fabric PCB – Sapphire Black PCB ASRock Ultra M.2 (PCIe Gen3 x4 & SATA3) ASRock Full Spike Protection (for all USB Audio LAN Ports) ASRock Live Update & APP Shop |
| CPU | – Supports AMD AM4 Socket Ryzen? 2000 3000 4000 G-Series 5000 and 5000 G-Series Desktop Processors – 6 Power Phase design – Supports CPU up to 105W |
| Chipset | – AMD Promontory B450 |
| Memory |
– Dual Channel DDR4 Memory Technology **Due to the operating system limitation the actual memory size may be less than 4GB for the reservation for system usage under Windows? 32-bit OS. For Windows? 64-bit OS with 64-bit CPU there is no such limitation. |
| BIOS | – 128Mb AMI UEFI Legal BIOS with GUI support – Supports “Plug and Play” – ACPI 5.1 compliance wake up events – Supports jumperfree – SMBIOS 2.3 support – DRAM Voltage multi-adjustment |
| Graphics | – Integrated AMD Radeon? Vega Series Graphics in Ryzen Series APU* – DirectX 12 Pixel Shader 5.0 – Shared memory default 2GB. Max Shared memory supports up to 16GB.** – Three graphics output options: D-Sub DVI-D and HDMI – Supports Triple Monitor – Supports HDMI with max. resolution up to 4K x 2K (4096×2160) @ 24Hz / (3840×2160) @ 30Hz – Supports DVI-D with max. resolution up to 1920×1200 @ 60Hz – Supports D-Sub with max. resolution up to 2048×1536 @ 60Hz – Supports Auto Lip Sync Deep Color (12bpc) xvYCC and HBR (High Bit Rate Audio) with HDMI Port (Compliant HDMI monitor is required) – Supports HDCP 1.4 with DVI-D and HDMI Ports – Supports 4K Ultra HD (UHD) playback with HDMI Port *Actual support may vary by CPU
**The Max shared memory 16GB requires 32GB system memory installed. |
| Audio | – 7.1 CH HD Audio (Realtek ALC887 Audio Codec) – Supports Surge Protection – ELNA Audio Caps |
| LAN | – PCIE x1 Gigabit LAN 10/100/1000 Mb/s – Realtek RTL8111H – Supports Wake-On-LAN – Supports Lightning/ESD Protection – Supports Energy Efficient Ethernet 802.3az – Supports PXE |
| Slots | – 4 x SATA3 6.0 Gb/s Connectors support RAID (RAID 0 RAID 1 and RAID 10) NCQ AHCI and Hot Plug – 1 x Ultra M.2 Socket supports M Key type 2242/2260/2280 M.2 SATA3 6.0 Gb/s module and M.2 PCI Express module up to Gen3 x4 (32 Gb/s) (with Matisse Picasso Summit Ridge Raven Ridge and Pinnacle Ridge) or Gen3 x2 (16 Gb/s) (with Athlon series APU)* *Supports NVMe SSD as boot disks
Supports ASRock U.2 Kit |
| Connector | – 1 x COM Port Header – 1 x TPM Header – 1 x Chassis Intrusion and Speaker Header – 1 x CPU Fan Connector (4-pin)* – 2 x Chassis Fan Connectors (1 x 3-pin 1 x 4-pin)** – 1 x 24 pin ATX Power Connector – 1 x 4 pin 12V Power Connector – 1 x Front Panel Audio Connector – 2 x USB 2.0 Headers (Support 4 USB 2.0 ports) (Supports ESD Protection) – 1 x USB 3.1 Gen1 Header (Supports 2 USB 3.1 Gen1 ports) (Supports ESD Protection) *The CPU Fan Connector supports the CPU fan of maximum 1A (12W) fan power.
**The Chassis Fan Connector supports the chassis fan of maximum 1A (12W) fan power. |
| Rear Panel I/O | – 1 x PS/2 Mouse/Keyboard Port – 1 x D-Sub Port – 1 x DVI-D Port – 1 x HDMI Port – 2 x USB 2.0 Ports (Supports ESD Protection) – 4 x USB 3.1 Gen1 Ports (Supports ESD Protection) – 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED) – HD Audio Jacks: Line in / Front Speaker / Microphone |
| Software and UEFI |
Software
– ASRock A-Tuning – ASRock XFast LAN UEFI – ASRock Full HD UEFI – ASRock Instant Flash – ASRock Easy RAID Installer *These utilities can be downloaded from ASRock Live Update & APP Shop.
|
| Support CD | – Drivers Utilities AntiVirus Software (Trial Version) Google Chrome Browser and Toolbar |
| Accessories | – Quick Installation Guide Support CD I/O Shield – 2 x SATA Data Cables – 1 x Screw for M.2 Socket |
|
Hardware Monitor
|
– CPU/Chassis temperature sensing – CPU/Chassis Fan Tachometer – CPU/Chassis Quiet Fan – CPU/Chassis Fan multi-speed control – CASE OPEN detection – Voltage monitoring: +12V +5V +3.3V Vcore |
| Form Factor | – Micro ATX Form Factor: 9.0-in x 7.9-in 23.0 cm x 20.1 cm – Solid Capacitor design |
|
OS
|
Microsoft? Windows? 10 64-bit |
|
Certifications
|
– FCC CE – ErP/EuP ready (ErP/EuP ready power supply is required) |
| Warranty | 3 Years |
| Note |
Unique Feature***Features Price and Specifications are subject to change without notice.
|
