FEATURES
Offers omnidirectional reading of virtually all linear barcodes and the most widely used 2D barcodes including poor-quality and mobile barcodes (2D decoding available in select models).
Scans coupons mobile tickets and digital wallets from the screens of mobile devices.
Delivers affordable scanning of 2D barcodes allowing enterprises to meet their current and future barcode scanning needs with a single device.
Meets diverse scanning requirements by offering models with basic functionality with flexible software licenses enabling additional functionality as needs evolve.
SPECIFICATIONS
| Model | Voyager 1450g |
| Mechanical | |
| Dimensions (LxWxH) | 62 mm x 169 mm x 82 mm (2.4 in x 6.6 in x 3.2 in) |
| Weight | 130 g (4.6 oz) |
| Electrical | |
| Input Voltage | 5 V ñ 5% |
| Operating Power | 2 W (400 mA @ 5V DC) |
| Standby Power | 0.45 W (90 mA @ 5V DC) |
| Host System Interfaces | USB Keyboard Wedge RS-232 IBM 46xx (RS485) |
| ENVIRONMENTAL | |
| Operating Temperature | 0øC to 40øC (32øF to 104øF) |
| Storage Temperature | -40øC to 60øC (-40øF to 140øF) |
| Humidity | Up to 95% relative humidity non-condensing |
| Drop | Designed to withstand 30 1.5 m (5 ft) drops to concrete |
| Tumble | Designed to withstand 1000 tumbles from 0.5 m (1.64 ft) |
| Environmental Sealing | IP40 |
| Light Levels | 0 to 100000 lux (9290 foot-candles) |
| SCAN PERFORMANCE | |
| Scan Pattern | Area Image (640 x 480 pixel array) |
| Motion Tolerance | Up to 10 cm/s (4 in/s) for 13 mil UPC at optimal focus |
| Scan Angle | Horizontal: 37.8ø Vertical: 28.9ø |
| Symbol Contrast | 35% minimum reflectance difference |
| Pitch Skew | ñ60ø ñ70ø |
| Decode Capability | 1450g1D: All standard 1D symbologies 1450gPDF: All standard 1D and PDF417 symbologies 1450g2D: All standard 1D PDF417 and 2D symbologies |
| Warranty | 5 Years |
| Note | ***Features Price and Specifications are subject to change without notice. |
