| Chipset |
AMD B650 |
| CPU SUPPORT |
- Supports AMD Ryzen? 7000 Series Desktop Processors
- Socket AM5
|
| Memory |
- 4x DDR5
- Maximum Memory Capacity 128GB
- Memory Support DDR5 6400+(OC)/6200(OC)/6000(OC)/5800(OC)/5600(OC)/5400(OC)/5200(OC)/5000(OC)/4800(JEDEC) MHz Max. overclocking frequency:
- 1DPC 1R Max speed up to 6400+ MHz
- 1DPC 2R Max speed up to 5800+ MHz
- 2DPC 1R Max speed up to 6000+ MHz
- 2DPC 2R Max speed up to 4000+ MHz Supports Dual-Channel mode Supports non-ECC
- un-buffered memory Supports AMD EXPO
|
| Onboard Graphics |
- 1x HDMI
- 1x DisplayPort
- Support HDMITM
- 2.1maximum resolution of 4K 60Hz
- Supports DP1.4
- maximum resolution of 4K 60Hz
|
| EXPANSION SLOT |
2x PCI-E x16 slot 1x PCI-E x1 slot PCI_E1 PCIe 4.0 supports up to x16 (From CPU) PCI_E2 PCIe 3.0 supports up to x1 (From Chipset) PCI_E3 PCIe 4.0 supports up to x4 (From Chipset) |
| Storage |
2x M.2 slot
- M.2_1 (From CPU) supports up to PCIe 4.0 x4 supports 2280/2260 devices
- M.2_2 (From CPU) supports up to PCIe 4.0 x4 supports 2280/2260 devices 4x SATA 6G port
|
| RAID |
Supports RAID 0 RAID 1 and RAID 10 for SATA storage devices Supports RAID 0 and RAID 1 for M.2 NVMe storage devices |
| USB |
- 4x USB 2.0 (Front)
- 4x USB 3.2 Gen1 Type A (Rear)
- 2x USB 3.2 Gen1 Type A (Front)
- 4x USB 3.2 Gen2 Type A (Rear)
- 1x USB 3.2 Gen2 Type C (Front)
|
| LAN |
Realtek? 8125BG 2.5G LAN |
| WIRELESS / BLUETOOTH |
- AMD Wi-Fi 6E The Wireless module is pre-installed in the M.2 (Key-E) slot Supports MU-MIMO TX/RX Supports 20MHz 40MHz 80MHz160MHz bandwidth in 2.4GHz/ 5GHz or 6GHz* bands Supports 802.11 a/ b/ g/ n/ ac/ ax Supports Bluetooth? 5.2**
|
| Audio |
- 1x Power Connector(ATX_PWR)
- 2x Power Connector(CPU_PWR)
- 1x CPU Fan
- 1x Pump Fan
- 3x System Fan
- 2x Front Panel (JFP)
- 1x Chassis Intrusion (JCI)
- 1x Front Audio (JAUD)
- 1x Com Port (JCOM)
- 1x Tuning Controller connector(JDASH)
- 2x Addressable V2 RGB LED connector (JARGB_V2)
- 2x RGB LED connector(JRGB)
- 1x TPM pin header(Support TPM 2.0)
- 4x USB 2.0
- 2x USB 3.2 Gen1 Type A
- 1x USB 3.2 Gen2 Type C
|
| LED FEATURE |
4x EZ Debug LED |
| OPERATING SYSTEM |
Support for Windows? 11 64-bit Windows? 10 64-bit |
| PCB Dimension |
mATX |
| Warranty |
3 Years |
| Note |
*** Features Price Specifications are subject to change without notice. |
